Graphix Inline

The Graphix Inline for integrated laser solutions on automated production lines.

Features

• Very simple implementation with two positioning diodes
• Robust machine with reduced service and maintenance due to long life diodes
• High speed marking for medium to large production runs
• Ergonimc design with compact light source, galvo head and lens that easily integrate in any position
• Auto diagnostic system with real time management of the laser operating state
• Possible to use a robot for simple functions (start, stop, end of marking, marking in progress etc.)
• Communications: RS232 port and Ethernet
• 3 dimension marking capabilities
• Compatible with every reading system on the market
• Can have up to 4 axes
• graphix inlinegraphix inline - alternative image a
• Make an Enquiry Make an Enquiry
• Videos
• Graphix Inline Brochure

Further Technical Data

• Output power 20W as standard
• Focal length adjustment pointer
• Electrical column 2 speeds 300mm travel
• 4 positions for the marking head
• Communications: 2 USB ports, 1 Ethernet port and 1 VGA port.
• Reduced maintenance
• Loading volume up to 500 x 500 x 300 mm
• Maximum stroke of 300 mm
• Electrical power: 100 to 240W
• Power/ frequency: 600W/ 50 to 60Hz
