Outer Pouch Packing Machine OPS 753-DL

Introduction

OPS 753-DL is double lane high output platen seal method machine for good stability in sealing process prior to sterilization

It is fully servo motor driven with the advanced servo synchronized system. It reduces down time and wastage; it has the flexibility of changing pouch dimension with simple tooling and conversion kits.

Can run as double lane or single lane ( depend on product requirements)

Features

• High output.

• Continuous sealing process with eye mark registration.

• Machine designed by modular conception allowing easy integration to others device.

• Large touch screen with PLC system for easy operating.

• Material compatible with both flexible and rigid film.

Technical Data

OPS SERIESOPS 753-DL

Machine Length5.4 m

Machine Width1.3 m

Pouch Lengthup to 300 mm

Pouch widthup to 180 mm

Capacityup to 150 ppm

Materials: Bottom FilmAll kind of heat sealable materials and composite foils Print unprinted Clear

Top FilmPre-printed film

Roll Sizeup to 600mm diameter

Core Size76mm diameter

Others

• QA System Empty Pouch detection.

• Reel Shaft Air Shaft type

• Optional Code Printer; ink jet printer or thermal coder may be integrated.

Machine UtilitiesElectrical Supplies 3-phase, 415V, 50/60Hz

Operating Pressure6.0 bar / 81psi
