Die cutting machine -TRC350

TRC350 is one of digital finished machine for die cut, coating, slitting, sheeting on roll to roll, equipped EPC, Corona, lamination etc. and available for customize specifications


Model TRC350
Max. materials width 340mm
Pneumatic cylinders 6(3” diameter)
Max. die cut speed 0~300/minute
Die cut length 50~300mm
Die cut unit One for 120T
Die cut thickness 0.2~0.5mm
Dies Flexible dies
Slitting blade 6
Power Consumption 220V 3 phases
Weights 2500Kg
Dimension 2312(L)x644(W)x1610(H)mm
