parcel sortation system
BEUMER SORTATION AND DISTRIBUTION TECHNOLOGY
HIGH PERFORMANCE AT THE RIGHT TIME, AT THE RIGHT PLACE
The BEUMER Group product range comprises fully automatic conveying and distribution systems for all kinds of piece goods. In courier, expedited and parcel services, mail-order businesses, retail distribution or airports: the computer controlled BEUMER sortation systems – which meet all modern standards of quality– stand for high levels of availability, low maintenance costs and a top performance of up to 40,000 units per hour.
Specific customer demands, such as optical character recognition (OCR) “on-the-fly”, certified weighing on the induction unit or certified volume measurement on the sorter, are no problem.
SMOOTH DISCHARGE
The BEUMER Tilt Tray Sorter is the basic model of our modular system. The mechanical tilt elements enable a guided, two-dimensional discharge of the items to both sides. This makes the item slide off the tray without any catapult effect so that it leaves the tray at a clearly lower speed than with comparable systems.
Large envelopes, parcels, packages and other sorting items are transported safely and discharged with maximum accuracy. The tilt element of the BEUMER E-Tray Sorter is driven by an electric motor. The tilt elements are powered by contactless energy supply. Thus the tilting and running noise is reduced. The tilting movement is decoupled from the sorter speed so that the sorter speed is considerably increased.
HIGHLIGHTS OF THE BEUMER
TILT TRAY SORTER
- Exceptional sorting quality
- Low-maintenance tilt element, electrical or mechanical
- Guided, two-dimensional discharge
- Low-maintenance, low-wear linear motor drive, alternatively the energy effi cient BEUMER OptiDrive® design
- Low-noise running characteristics
