TECHNICAL SPECIFICATIONS
Label Height : 8 mm to 70/90/120/150/180 mm Standard*
Label Length : 12 mm Minimum
Label Roll Dia. : 300 mm
Core Dia. : 75/76 mm
Gap Between two Labels : appx. 3 mm or more
Product Size : As per customers requirements*
Feed Worm and / or Pocket System require for change in Bottle size as change parts.
Electrical : 220 VAC Single Phase Power Supply (50/60 Hz)
Power : 1.0 Hp, 2.0 Amp.
Capacity : 0.75 Kw
Speed : Up to 100 Labels per minute depending on Product and Label Size and upto 240 Labels per minute for Model LABELSTIK-250F.Twin, The speed is also depending on stable movement of product on machine conveyor at higher speed.
Conveyor height : 830-875 mm*
Overall dimension : 2440 mm(L) X 1640 mm(W) X 1500 mm (H)
With T.G. Cabinet : 2440 mm(L) X 1640 mm(W) X 1900 mm (H)
Machine Direction of Movement : Left to Right from operator side
UTILITY REQUIRED :
Power : 2.0 Hp
Electrical : 220 VAC Single Phase Power Supply (50 Hz) or 415VAC 3Phase
Compressed Air : 5 - 6 Bar Required if opted for Ejection / Rejection System
* Specification can be changed as per customers requirements
Note: Bottle having narrow bottom compare to top body portion is required to feed / handle by operator manually to avoid bottle falling on machine conveyor.
|
